Specifications
High production Automatic Double Twist Barbed Wire mesh Making Machine
1. Wire diameter: 1.6mm-2.8mm
2. Working time: 10-15 years
3. Worker demand: One
4. ISO9001: 2008
XINGMAO New Design Automatic Double Strand Twisted Barbed Wire Machine Manufacturer
1)Single twisted barbed wire netting machine is designed to produce screens with sing or double stranded barbed steel wire, thermo-plated with zinc. The machine is of together at the middle. It is safe and reliable in operation, capable of turning out high quality products with consistency.
2)Double twisted bared wire netting machine is designed to produce screens with sing or double stranded barbed steel wire, thermo-plated with zimc. The machine is of horizontal design, , consisting of two parts, assembled together at the middle. It is safe and reliable in operation, capable of turning out high quality products with consistency.
1, CS-A Double twisted Barbed Wire Machine is designed to produce screens with single or double-strand barbed steel wire, thermo-plated with zinc. The machine is of horizontal design, consisting of two parts, assembled together at the middle. It is safe and reliable in operation, capable of turning out high quality products with consistency.
2, CS-B single twisted Barbed Wire Machine is designed to produce screens with single or double-stranded barbed steel wire, thermo-plated with zinc. The machine is of horizontal design, consisting of two parts, assembled together at the middle. It is safe and reliable in operation, capable of turning out high quality products with consistency.
3. CS-C Barbed Wire Machine for Two-strand Wire with Two-way Twistsis for Two-strand Wire with Two-way Twists can produce the barbed wire with two-way twists. This way is easy to operate and install as they will not entwist with each other.
best price used barbed wire machine for sale
Barbed wire machine could be classified into three types:normal double twisted barbed wire machine,reverse twisted barbed wire machine and single twisted barbed wire machine.It can produce double twisted barbed wire and single twisted barbed wire which is widely used in national defense,military, railway,highway agriculture animal husbandry and other industries. the material of barbed wire is usually hot dipped galvanized wire, electric galvanized wire and pvc coated wire etc.
Barbed wire machine is used to make double barbed wire which is widely used on
the airport, miltary, railway, highway, agriculture, animal husbandry and so on.
barbed wire machine: can produce
barbed wire single or double twisted
Stranded barbed steel wire,
thermo-plated with zinc.
Barbed wire machine:
Our barbed Wire Machine is designed to produce barbed wire single or double twisted. Stranded barbed steel wire, thermo-plated with zinc. The machine is of horizontal design, consisting of two parts, assembled together at the middle. It is safe and reliable in operation, capable of turning out high quality products with consistency.
| Model |
CS-A |
CS-B |
CS-C |
| Motor |
2.2KW |
2.2KW |
2.2KW |
| Main drive shaft speed |
402r/min |
355r/min |
355r/min |
| wire diameter (mm) |
2.2-3.0 |
2.2-3.0 |
1.6-2.2 |
| Barbed wire diameter(mm) |
1.8-2.2 |
1.8-2.2 |
1.6-2.2 |
| Barbed space (mm) |
76, 102, 127 |
102, 127 |
102, 127 |
| Twisted number |
3-5 |
|
7 |
| theoretical production |
77 kg/h |
40 kg/h |
40 kg/h |
| weight |
1000kg |
950kg |
950kg |
| Main part size(mm) |
1950*950*1300 |
3100*1000*1150 |
3100*1000*1150 |
V.Commercial terms
1. FOB price: Barbed Wire Machine CS-A: 4380 USD FOB Xingang Port, China
2. Payment: 30% T/T in advance, the balance 70% by T/T after check the machine at seller's factory.
3. Minimum order quantity: 1 set
4. Certification: ISO 9001 Certificate
5. Delivery time: 30 days from received your payment in advance.
6. Country of origin: China
7. Our guarantee time: 12 months after the equipment is accepted by the buyer, however, the guarantee period is no longer than 18 months after equipment's departure from Xingang port, China.
8. Installation: we could arrange our engineer install the machine in your factory.
7. Our guarantee time: 12 months after the equipment is accepted by the buyer, however, the guarantee period is no longer than 18 months after equipment's departure from Xingang port, China.
8. Installation: we could arrange our engineer install the machine in our factory.
Our service:
1. Guarantee period: 12 months (but no longer than 18 months since departure from Xingang Port)
2. Our engineers are available to install and maintain machine overseas.
3. Customized machine.
4. OEM support.
5. Fast delivery.
6. Moderate price.
7. Door to Door service or 24-hour email service.
