| Place of Origin: | china |
| Brand Name: | XM |
| Certification: | iso 9001 |
| Model Number: | Ni 200 |
| Minimum Order Quantity: | 100m2 |
|---|---|
| Price: | 100usd-200usd |
| Packaging Details: | Waterproof Paper and Plastic Cloth and Wooden Box |
| Delivery Time: | within 7days from we got the payment |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 10000m2/month |
| Nickels: | 99.9% | Mesh: | 2-500mesh |
|---|---|---|---|
| Wire Mesh Width: | 1m,1.2m | Weave: | Plain & Twill |
| Specification: | 40mesh, 60mesh | Transport Package: | Waterproof Paper And Plastic Cloth And Wooden Box |
Nickel Woven Wire Mesh
Nickel Wire Mesh/Nickel screen is made of high purity nickel wire. It has outstanding resistance to acids and alkalis. Nickel Wire Mesh is widely used in corrosive environments as for filtration of liquid, gas, etc.
Plain woven nickel wire mesh is one of the most populary used mesh type. It has outstanding stability and filter precision properties.
The characteristics of plain woven nickel wire mesh:
Each weft wire passes over one and under one warp wire, and each warp wire passes over one and under one weft wire, every weft wire have and warp wire the same diameter. Fabric shall be formed by spacing the main and cross wires at a right angle. When the entire main and cross wires are parallel and equally intervals, the mesh forms a square, and, when the width is different, it becomes rectangular.
Nickel Woven Wire Mesh Specification
| Mesh Size | Wire Thickness (mm) |
| 20 x 20 | 0.18 |
| 40 x 40 | 0.15 |
| 60 x 60 | 0.12 |
| 80 x 80 | 0.10 |
| 100 x 100 | 0.08 |
| 120 x 120 | 0.07 |
| 140 x 140 | 0.07 |
| 160 x 160 | 0.055 |
| 180 x 180 | 0.05 |
| 200 x 200 | 0.05 |
| 124 x 84 | 0.08 |
Product Description
Nickel Wire Mesh For Chlor Alkali Chemical Industry(40 Mesh Ni200).
Details:
| Product name | 40 Mesh UNS N02200 Pure Wrought Nickel Wire Mesh/Cloth |
| Grade | UNS N02200/W.Nr.2.4060/N6/Nickel 200 |
| Wire Diameter | 0.17mm |
| Aperture Size | 0.5mm |
| Mesh from | 40 mesh/inch |
| Weaving Pattern | plain |
| Size | 500mmX1000mm |
| Denstiy | 8.89g/cm3 |
| M. point | 1435-1446°C |
| Nickel 200 wire mesh Features |
Nickel 200 (UNS N02200) is a commercially pure wrought nickel, with good mechanical properties and an excellent resistance to many corrosive environments. Alloy 200 has good thermal, electrical and magnetostrictive properties. Nickel 200 Characteristic as below: 1.Highly resistant to various reducing chemicals 2.Excellent resistance to caustic alkalies 3.High electrical conductivity 4.Excellent corrosion resistance to distilled and natural waters 5.Resistance to neutral and alkaline salt solutions 6.Excellent resistance to dry fluorine 7.Widely used to handle caustic soda 8.Good thermal, electrical and magnetostrictive properties 9.Offers some resistance to hydrochloric and sulfuric acids at modest 10.temperatures and concentrations. |
| Nickel 200 wire mesh Applications |
Nickel 200 Application field : 1.Food processing equipment 2.Marine and offshore engineering 3.Salt production 4.Caustic handling equipment 5.Manufacture and handling of sodium hydroxide, particularly at 6.temperatures above 300° F 7.Reactors and vessels in which fluorine is generated and reacted with hydrocarbons |
Application
1. For vacuum coating;
2. For making valves grid, inner components of vacuum valves;
3. For making lead, supporting wire;
4. For battery production;
5. For chemical, mine, hydrogen making, acid making and basic industry.
